Product features and description:

Parameters of a DELUX sandwich panel mobile home with default settings, habitable all year round:

• Width and length: 8x5m (40m² floor area)
• Roof type: sloping roof with trapezoidal sheet roof cladding, class I sandwich panel (thickness: 120 mm)
• Height: maximum height 2,80m / minimum height 2,50m
• Door type: 1 left, insulated, glazed, aluminium, 0,9x2m - entrance to the living area
• Windows: 2 windows (120x90cm, double-glazed, double-paned, double-hung, thermally insulated, plastic) on the left side of the building and on the bedroom wall, 1 window (50x50cm, double-glazed, double-hung, thermally insulated, plastic) on the bathroom wall at the back of the building
• Frame construction: solid, galvanised steel frame
• Edging: on the corners and roof of the building
• Riveting: coloured rivets on the side walls in harmony with the plate cover
• Walls: class I coloured sandwich panel (thickness: 120mm)
• Internal walls: 100 mm thick PIR panel partitions
• Floor construction: 100 mm thick PIR panel + 18 mm thick OSB board
• Colours: white (walls), anthracite grey 7016 (door, window, roof)
• Gutter: on the rear side of the roof, with right or left hand drain, in grey
• Fixing: with concrete pins to a horizontal base duly prepared by the Client

In addition to the above parameters, the insulated mobile home (four-season container house) can be modified with the following accessories:

• additional door, window, room separated by internal walls inside the building

In addition, you can of course make modifications such as changing the basic size of the sandwich panel mobile home, the location of the windows, the colour of the cladding, the direction of the roof pitch, etc. During the request for proposal, please indicate the requested modifications and additions and we will send you an e-mail with the requested changes. The order will be finalized only after the requested clarifications and acceptance of the offer.

A DELUX the price of a quality sandwich panel mobile home (container house) includes the manufacture, transport, assembly and fixing of the building to the base prepared by you.

It's your job:

• Providing a horizontally prepared concrete base
• Electrical and plumbing installation work
• Interior finishing, including laying laminate flooring/surfacing and installation of interior doors

Available versions:

• BERGEN - 1 bedroom version
• MOTALA - 1 bedroom + separate entrance storage room version (with 2 doors)

Insulation types:

EPS (polystyrene foam) - one of the most popular insulation materials due to its lower cost
PIR (rigid polyurethane foam) - an improved version of PUR foam

PIR insulation in a thinner form can produce as good an effect as thicker EPS insulation. It can achieve nearly 40 percent better insulation than EPS boards.
